COB,引擎,模块,灯条
图片 | 零件编号 | 制造商 | 数据表 | 价格(美元) | 应用 | 产品分类 | 备注 | 数量 | 询盘 |
类型 |
Color |
Height |
系列 |
CCT (K) |
包装 |
Features |
Lens Type |
Wavelength |
部件状态 |
Configuration |
Current - Max |
Viewing Angle |
Current - Test |
尺寸 |
Temperature - Test |
CRI (Color Rendering Index) |
Light Emitting Surface (LES) |
Lumens/Watt @ Current - Test |
Voltage - Forward (Vf) (Typ) |
Luminous Flux @ Current/Temperature |
Flux @ Current/Temperature - Test |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
(Alternative models available) |
Bridgelux, Inc. |
1+: $2 10+: $1.98 100+: $1.96 500+: $1.94 1000+: $1.92 |
Wired networking |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Bridgelux, Inc.. |
9759 In Stock | Chip On Board (COB) | White, Warm / White, Cool | 1.65mm | Vesta™ | 3850K (2700K ~ 5000K) 3-Step MacAdam Ellipse | Tube | - | Flat | - | Active | Square | 700mA | 130° | 500mA | 15.90mm L x 15.90mm W | 25°C | 92 | 10.00mm Dia | 126 lm/W | 18V | 1153lm (Typ) | - | |||
(Alternative models available) |
Cree |
1+: $1 10+: $0.99 100+: $0.98 500+: $0.97 1000+: $0.96 |
Hybrid, electric & powertrain systems Motor drives Home theater & entertainment |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
8551 In Stock | Chip On Board (COB) | White, Cool | 1.70mm | Xlamp® CXB1304 | 6500K 5-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 500mA | 115° | 200mA | 13.35mm L x 13.35mm W | 85°C | 80 | 6.00mm Dia | 127 lm/W | 18V | 458lm (440lm ~ 475lm) | - | |||
(Alternative models available) |
Cree |
1+: $2 10+: $1.98 100+: $1.96 500+: $1.94 1000+: $1.92 |
Appliances Motor drives |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
4746 In Stock | Chip On Board (COB) | White, Warm | 1.70mm | XLamp® CXA1507 | 3500K 4-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 750mA | 115° | 400mA | 15.85mm L x 15.85mm W | 85°C | 93 | 8.90mm Dia | 79 lm/W | 18V | 570lm (550lm ~ 590lm) | - | |||
(Alternative models available) |
Citizen Electronics Co., Ltd. |
1+: $5 10+: $4.95 100+: $4.9 500+: $4.85 1000+: $4.8 |
Body electronics & lighting |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Citizen Electronics Co., Ltd.. |
7967 In Stock | Chip On Board (COB) | White, Cool | 1.40mm | CLU026 | 5000K 3-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 460mA | - | 180mA | 13.50mm L x 13.50mm W | 85°C | 80 | 9.80mm Dia | 147 lm/W | 34.6V | 918lm (Typ) | - | |||
(Alternative models available) |
NTE Electronics, Inc. |
1+: $70 10+: $69.3 100+: $68.6 500+: $67.9 1000+: $67.2 |
Building automation Motor drives |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: NTE Electronics, Inc.. |
5137 In Stock | LED Module | Pink | 4.00mm | - | - | Bag | IP68 | Flat | 454nm (453nm ~ 455nm) | Active | Linear Light Strip, Flexible | - | 120° | - | 5000.00mm L x 10.25mm W | - | - | - | - | 12V | - | - | |||
(Alternative models available) |
Cree |
1+: $7 10+: $6.93 100+: $6.86 500+: $6.79 1000+: $6.72 |
Infotainment & cluster Data center & enterprise computing TV |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
964 In Stock | Chip On Board (COB) | White, Warm | 1.70mm | XLamp® CXA2540 | 3000K 2-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 2.1A | 115° | 1.1A | 23.85mm L x 23.85mm W | 85°C | - | 19.00mm Dia | 87 lm/W | 37V | 3560lm (3440lm ~ 3680lm) | - | |||
(Alternative models available) |
Luminus Devices |
1+: $5 10+: $4.95 100+: $4.9 500+: $4.85 1000+: $4.8 |
Advanced driver assistance systems (ADAS) |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Luminus Devices. |
5952 In Stock | Chip On Board (COB) | White, Warm | 1.37mm | CHM-9 | 3500K 2-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 1.05A | 120° | 720mA | 19.00mm L x 19.00mm W | 85°C | 95 | 9.00mm Dia | 73 lm/W | 36V | 1890lm (Typ) | - | |||
(Alternative models available) |
Cree |
1+: $4 10+: $3.96 100+: $3.92 500+: $3.88 1000+: $3.84 |
Datacom module Power delivery TV |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
8822 In Stock | Chip On Board (COB) | White, Neutral | 1.70mm | XLamp® CXA1820 | 4000K | Tray | - | Flat | - | Active | Square | 1.05A | 115° | 550mA | 17.85mm L x 17.85mm W | 85°C | 80 | 12.00mm Dia | 123 lm/W | 37V | 2510lm (2420lm ~ 2600lm) | - | |||
(Alternative models available) |
Lite-On, Inc. |
1+: $1 10+: $0.99 100+: $0.98 500+: $0.97 1000+: $0.96 |
Hybrid, electric & powertrain systems Grid infrastructure Portable electronics |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Lite-On, Inc.. |
6608 In Stock | Chip On Board (COB) | White, Warm | 1.60mm | LTPL | 3000K 3-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 150mA | 120° | 100mA | 13.35mm L x 13.35mm W | 25°C | 80 | 6.30mm Dia | 125 lm/W | 36.8V | 460lm (Typ) | - | |||
(Alternative models available) |
Bridgelux, Inc. |
1+: $5 10+: $4.95 100+: $4.9 500+: $4.85 1000+: $4.8 |
Broadband fixed line access Medical Tablets |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Bridgelux, Inc.. |
9870 In Stock | Chip On Board (COB) | White, Cool | 3.60mm | Vero® SE 13 Array | 6500K 3-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Round | 1.26A | 120° | 630mA | 36.20mm Dia | 85°C | 80 | 13.40mm Dia | 156 lm/W | 33.9V | 3335lm (Typ) | - | |||
(Alternative models available) |
Cree |
1+: $1 10+: $0.99 100+: $0.98 500+: $0.97 1000+: $0.96 |
Datacom module Medical Portable electronics |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
2384 In Stock | Chip On Board (COB) | White, Warm | 1.70mm | XLamp® CXA1304 | 3000K 2-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 1A | 115° | 400mA | 13.35mm L x 13.35mm W | 85°C | 93 | 6.00mm Dia | 95 lm/W | 9V | 343lm (330lm ~ 355lm) | - | |||
(Alternative models available) |
Cree |
1+: $5 10+: $4.95 100+: $4.9 500+: $4.85 1000+: $4.8 |
Body electronics & lighting Data center & enterprise computing Portable electronics |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
4036 In Stock | Chip On Board (COB) | White, Cool | 1.70mm | Xlamp® CXB1830 | 6500K 5-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 1.4A | 115° | 800mA | 17.85mm L x 17.85mm W | 85°C | 70 | 14.00mm Dia | 152 lm/W | 36V | 4388lm (4230lm ~ 4545lm) | - | |||
(Alternative models available) |
Citizen Electronics Co., Ltd. |
1+: $7 10+: $6.93 100+: $6.86 500+: $6.79 1000+: $6.72 |
Wired networking Enterprise projectors |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Citizen Electronics Co., Ltd.. |
22 In Stock | Chip On Board (COB) | White, Warm | 1.40mm | CLU028 | 3500K 3-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 460mA | - | 180mA | 13.50mm L x 13.50mm W | 85°C | 80 | 9.80mm Dia | 150 lm/W | 34.6V | 937lm (Typ) | - | |||
(Alternative models available) |
Bridgelux, Inc. |
1+: $2 10+: $1.98 100+: $1.96 500+: $1.94 1000+: $1.92 |
Appliances Connected peripherals & printers |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Bridgelux, Inc.. |
4036 In Stock | Chip On Board (COB) | White, Warm | 1.70mm | Gen 7 V10 Array | 3500K 2-Step MacAdam Ellipse | - | - | Flat | - | Active | Square | 540mA | 120° | 270mA | 13.50mm L x 13.50mm W | 85°C | 80 | 10.20mm Dia | 142 lm/W | 33.8V | 1302lm (Typ) | - | |||
(Alternative models available) |
Luminus Devices |
1+: $7 10+: $6.93 100+: $6.86 500+: $6.79 1000+: $6.72 |
Lighting Test & measurement |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Luminus Devices. |
3855 In Stock | Chip On Board (COB) | White, Warm | 1.37mm | CXM-18 | 3000K 2-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 1.6A | 120° | 800mA | 21.50mm L x 21.50mm W | 85°C | 80 | 17.50mm Dia | 118 lm/W | 35V | 3295lm (3210lm ~ 3380lm) | - | |||
(Alternative models available) |
Cree |
1+: $6 10+: $5.94 100+: $5.88 500+: $5.82 1000+: $5.76 |
Appliances Home theater & entertainment |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
720 In Stock | Chip On Board (COB) | White, Warm | 1.70mm | Xlamp® CXB1830 | 2700K 2-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 1.4A | 115° | 800mA | 17.85mm L x 17.85mm W | 85°C | 80 | 14.00mm Dia | 124 lm/W | 36V | 3560lm (3440lm ~ 3680lm) | - | |||
(Alternative models available) |
NTE Electronics, Inc. |
1+: $50 10+: $49.5 100+: $49 500+: $48.5 1000+: $48 |
Data center & enterprise computing |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: NTE Electronics, Inc.. |
6259 In Stock | LED Module | Green | 2.20mm | - | - | Bag | IP20 | Flat | 518nm (510nm ~ 525nm) | Active | Linear Light Strip, Flexible | - | 120° | - | 5000.00mm L x 8.00mm W | - | - | - | - | 12V | - | - | |||
(Alternative models available) |
Cree |
1+: $10 10+: $9.9 100+: $9.8 500+: $9.7 1000+: $9.6 |
Broadband fixed line access Gaming |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
8147 In Stock | Chip On Board (COB) | White, Warm | 1.70mm | XLamp® CXA2540 | 3000K | Tray | - | Flat | - | Active | Square | 2.1A | 115° | 1.1A | 23.85mm L x 23.85mm W | 85°C | - | 19.00mm Dia | 94 lm/W | 37V | 3818lm (3680lm ~ 3955lm) | - | |||
(Alternative models available) |
Samsung Semiconductor |
1+: $8 10+: $7.92 100+: $7.84 500+: $7.76 1000+: $7.68 |
Aerospace & defense Medical Mobile phones |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Samsung Semiconductor. |
6429 In Stock | LED Module | White, Warm | 5.80mm | LT-M552B | 3500K 3-Step MacAdam Ellipse | Tray | With Connector | Flat | - | Obsolete | Linear Light Strip | - | 115° | 600mA | 550.00mm L x 18.00mm W | 50°C | 80 | - | 133 lm/W | 24.7V | 1970lm (Typ) | - | |||
(Alternative models available) |
Philips (LUMILEDS) |
1+: $17 10+: $16.83 100+: $16.66 500+: $16.49 1000+: $16.32 |
Test & measurement |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Philips (LUMILEDS). |
3260 In Stock | Chip On Board (COB) | White, Warm | 1.50mm | LUXEON CoB Core Range | 3000K 3-Step MacAdam Ellipse | Tube | - | Flat | - | Obsolete | Rectangle | 900mA | 115° | 450mA | 20.00mm L x 24.00mm W | 85°C | 80 | 13.00mm Dia | 129 lm/W | 35V | 2025lm (Typ) | - | |||
(Alternative models available) |
Cree |
1+: $2 10+: $1.98 100+: $1.96 500+: $1.94 1000+: $1.92 |
Electronic point of sale (EPOS) |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
7529 In Stock | Chip On Board (COB) | White, Neutral | 1.70mm | Xlamp® CXB1304 | 4000K 2-Step MacAdam Ellipse | Tray | - | Flat | - | Active | Square | 500mA | 115° | 200mA | 13.35mm L x 13.35mm W | 85°C | 90 | 6.00mm Dia | 132 lm/W | 17.3V | 458lm (440lm ~ 475lm) | - | |||
(Alternative models available) |
Luminus Devices |
1+: $107 10+: $105.93 100+: $104.86 500+: $103.79 1000+: $102.72 |
Body electronics & lighting Motor drives Portable electronics |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Luminus Devices. |
8732 In Stock | LED Module | Blue | 5.61mm | PT-121 | - | Tray | With Connector | Flat | 462nm | Active | Rectangle | 27A | - | 18A | 28.00mm L x 42.00mm W | 40°C | - | 3.00mm L x 4.00mm W | 15 lm/W | 3.9V | 1050lm (880lm ~ 1220lm) | - | |||
(Alternative models available) |
Cree |
1+: $0 10+: $0 100+: $0 500+: $0 1000+: $0 |
Appliances Pro audio, video & signage |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
2918 In Stock | Chip On Board (COB) | White, Cool | 1.70mm | XLamp® CXA1304 | 5000K | Tray | - | Flat | - | Active | Square | 500mA | 115° | 200mA | 13.35mm L x 13.35mm W | 85°C | 70 | 6.00mm Dia | 118 lm/W | 18V | 425lm (410lm ~ 440lm) | - | |||
(Alternative models available) |
American Bright |
1+: $110 10+: $108.9 100+: $107.8 500+: $106.7 1000+: $105.6 |
Aerospace & defense Motor drives |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: American Bright. |
7312 In Stock | LED Module | Red, Green, Blue, White (RGBW) | 11.80mm | AB-FF | - | Bag | IP68 | Flat | 625nm Red, 528nm Green, 470nm Blue | Active | Linear Light Strip, Flexible | - | 90° | 1.25A Red, 1.25A Green, 1.25A Blue, 1.25A White | 5000.00mm L x 22.00mm W | 25°C | 80 | - | 10 lm/W Red, 38 lm/W Green, 8 lm/W Blue, 50 lm/W White | 12V | 60lm Red, 190lm Green, 40lm Blue, 250lm White | - | |||
(Alternative models available) |
Cree |
1+: $8 10+: $7.92 100+: $7.84 500+: $7.76 1000+: $7.68 |
Building automation |
Products:光电器件--COB,引擎,模块,灯条 |
Manufacturers: Cree. |
4606 In Stock | Chip On Board (COB) | White, Cool | 1.55mm | Xlamp® CXB1310 | 6500K 5-Step MacAdam Ellipse | - | Flat | - | Active | Square | 700mA | 115° | 350mA | 13.35mm L x 13.35mm W | 85°C | 70 | 6.00mm Dia | 131 lm/W | 36V | 1650lm (1590lm ~ 1710lm) | - |
